Size |
9.1 x 2.9 x 2.2 in (230 x 74 x 55 mm) (with boot) |
Weight |
24.9 oz (708 g) (w/boot) |
Sensor |
Photo-ionization sensor with standard 10.6 eV lamp
(9.8 eV lamp in MP186)* |
Response Time |
3 sec (t90) VOC Mode
45 sec @ 68°F (20°C) Benzene Tube Mode (MP186) |
Accuracy |
±3% (at calibration point) |
Battery /
Run Time |
Rechargeable Lithium-Ion battery with 24 hours typical
operation |
Keypad |
4 Operation keys |
Sampling Pump |
Built-in pump with 3 settings from 300 to 430 cc/min
Sample from up to 100 ft (30 m) |
Display |
128 x 128 graphical LCD, 1.77 x 1.73 in (45 x 44 mm),
With LED backlight for enhanced display readability |
Direct Readout |
Real-time reading of gas concentration (ppb, ppm,
mg/m3
, μg/m3
), PID measurement gas and correction
factor, lamp on/off, Man-Down alarm on/off, battery
status, pump status, datalogging on/off, wireless
on/off, temperature and time |
Alarms |
Audible (95 dB @ 30 cm), visual (flashing bright red
LEDs ), and on-screen indication of alarm conditions
plus wireless remote alarm notification
High, Low, TWA and STEL alarms
Over range alarm, battery low alarm
Man-Down alarm with pre-alarm and real-time re-
mote wireless notification |
Datalogging
Capacity |
Standard 12 months at one-minute intervals
Storage interval adjustable from 1 to 3,600 seconds |
Calibration |
Two/three-point calibration |
Low Flow Alarm |
Auto pump shutoff at low-flow condition |
Charging and
Communication |
Charging, data download, instrument configuration
and firmware upgrades on PC or laptop via Micro
USB. Configuration also via BLE using mobile App on
Android phone or tablet |
BLE Range |
10 m (33 ft) line of sight |
Correction
Factors |
Integrated Correction Factor list of more than 700
compounds |
IP Rating |
IP-66/67 |
EMI/RFI |
Highly resistant to EMI/RFI
Compliant with EMC Directive 2014/30/EU |
Safety
Certifications |
Class I, Div 1, Group ABCD
T4, -20°C ≤ Tamb ≤ +50°C
IECEx Ex ia IIC T4 Ga
II 1G Ex ia IIC T4 Ga
European Conformity |
Temperature |
-4° to 122°F (-20° to 50°C) |
Humidity |
0% to 95% Relative humidity (non-condensing) |
Attachments |
Durable rubber boot, color coded for different models;
Tube holder for MP186 |
Warranty |
2 Years including lamp and sensor
(1-year for 9.8 eV lamp) |
