Pan/Tilt Range |
Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°, auto ip 180° |
Manual Control Speed |
Pan: 0.1° ~300° /s; Tilt: 0.1° ~200° /s |
Preset Speed |
Pan: 400° /s; Tilt: 300° /s |
Preset |
300 |
PTZ Mode |
5 Pattern, 8 Tour, Auto Pan, Auto Scan |
Speed Setup |
Human-oriented focal length/ speed adaptation |
Power up Action |
Auto restore to previous PTZ and lens status after power failure |
Idle Motion |
Activate Preset/ Pan/ Scan/ Tour/ Pattern if there is no command in
the specied period |
IR Distance |
100m |
Compression |
H.264 / MJPEG |
Resolution |
1.3M(1280× 960)/ 720P(1280× 720) / D1(704× 576/ 704× 480) /CIF
(352× 288/352× 240) |
Frame Rate |
Main Stream : 1.3M/ 720P (1 ~ 25/30fps)
Sub Stream 1: D1/CIF(1 ~ 25/30fps)
Sub Stream 2: 720P/ D1/ CIF (1 ~ 25/30fps) |
Bit Rate |
H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps |
Compression |
G.711a / G.711Mu(32kbps)/ PCM(128kbps) |
Interface |
1/1 channel In/Out |
IVS (optional) |
Tripwire, Intrusion, Abandoned Object Detection, Missing Object Detection |
Face Detection |
Support |
Ethernet |
RJ-45 (10/100Base-T) |
Protocol |
IPv4/ IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP,
RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS,
Bonjour, 802.1x |
Compatibility |
ONVIF PSIA CGI |
Max. User Access |
20 users |
Smart Phone |
iPhone, iPad, Android, Windows Phone |
Memory SlotM |
Micro SD, Max 128GB |
Alarm |
2/1 channel In/Out |
Power Supply |
AC24V, POE Plus(802.3at) |
Power Consumption |
13W, 23W (IR on) |
Working Environment |
-40oC ~ 70oC / Less than 90% RH |
Ingress Protection |
IP66 |
Dimensions |
Φ186.0(mm) x 309(mm) |
Weight |
3.5kg |
