• Application: Waste water / water, chemical, food & pharma etc
• Conductivity: >5 us
• Line size: DN 25mm-DN3000mm
• Liner: PTFE / Hard Rubber/ Electrode – SS316
• Electrode: SS316L / Hastelloy / Titanium & Platinum
• Velocity: O.Ohn/s to 10m/s
• Accuracy: ±0.5%
• Op Press: 40bar, Opt temp: 60 °C - 135°C
• Output: 4-20mA, RS485 : Pulse
• Communication: HART / RS485 / GPRS / GSM
• Material & Housing: MS & SS, Flow tube is completely welded
• Protection: IP65 / 67 / 68
• Power supply: 230 VAC / 24 VDC

Product Size Availability

Line Size : 1 Inch, 1.5 Inch, 2 Inch 2.5 Inch, 4 Inch & 8 Inch… etc
